Description
| Dimensions | |
| Width | 22.5 mm |
| Height | 96 mm |
| Depth | 110.4 mm |
| Weight | 90 g |
| Electrical data | |
| Power supply | 24 V DC |
| Power consumption during operation (cyclical data exchange) |
100 mA |
| Status display | LED |
| Environmental conditions | |
| Ambient temperature | 0 – 60 °C |
| Storage temperature | – 25 – 60 °C |
| Humidity | 93 % (at 40 °C) |
| Condensing | Not allowed |
| Protection classControl cabinet Housing Terminal area |
IP54 IP20 IP20 |
| Assembly data | |
| DIN rail | 35 x 7.5 mm |
| Height | 96 mm |
| Depth | 110.4 mm |
| DMX protocol | |
| Protocol | DMX 512 |
| Communication type | Unidirectional A sender sends the data without receiving feedback. A receiver accepts the data on the bus without feedback. |
| Baudrate | 250 kBaud |
| Transmission | RS 485 |
| Byte transmission | 8N2 (8 data bits, no parity, 2 stop bits) |
| Special feature | A DMX package starts with 88 us (22 bit lengths) low level (logical 0). This section is called “break”. |
