Housing dimensions (H x W x D) | 96 x 22.5 x 110.5 mm |
Housing type | DIN rail housing (for DIN rail version EN 50022) |
Housing material | Polycarbonate |
Weight | approx. 115 g |
IP Code | IP20 |
Power supply | power supply via ConBridge |
Operating temperature | 0 °C....+60 °C |
Storage temperature | -40 °C....+70 °C |
Humidity (at 40°C) | 93% (non-condensing) |
Connectors | SMA jack (female) |
Optical indicator | 1 status LED (green) |
M-Bus module | Radiocraft RC1180-MBUS3 |
Frequency band | 868 MHz |
Number of radio channels | 12 |
RF data rate | 4.8, 32, 100 kbps |
RX sensitivity | -106/-102/-101 dBm |
Indicative LOS (indicative Line-of-Sight) | max. 500 m |
Connection compatibility | Exclusively connectable via ConBridge of RevPi Connect |
CE conformity | Yes (only in combination with 0 dBm antenna) |
RoHS conformity | Yes |
ESD test | Passed (according to EN 61000-4-2) |
