Description
| Housing dimensions (H x W x D) | 96 x 22.5 x 110.5 mm |
| Housing type | DIN rail housing (for DIN rail version EN 50022) |
| Housing material | Polycarbonate |
| Weight | approx. 115 g |
| Protection class | IP20 |
| Power supply | min. 10.7 V – max. 28.8 V [1] |
| Max. power consumption | 10 Watt (incl. 2 x 450 mA USB load) [2] |
| Operating temperature | -40 °C to +55 °C (exceeds EN 61131-2 requirements) [3] |
| Storage temperature | -40 °C to +85 °C (exceeds EN 61131-2 requirements) |
| Humidity (40°C) | up to 93% (non-condensing) |
| Interfaces | 2 x USB 2.0 A (each can be charged with 500mA) | 1 x Micro-USB | 1 x Micro HDMI | 1 x RJ45 (Ethernet) 10/100 Mbit/s |
| Processor | BCM2837, 1.2 GHz, quad-core |
| RAM | 1 GByte |
| Flash | 4 GByte |
| Polarity protection | Yes |
| ESD protection | 4 kV / 8 kV (according to EN 61131-2 and IEC 61000-6-2) |
| EMI tests | Passed (according to EN 61131-2 and IEC 61000-6-2) |
| Surge/Burst tests | Passed (according to EN 61131-2 and IEC 61000-6-2 using power supply , Ethernet line und IO lines) |
| Buffer time RTC | min. 24 h |
| Optical indicator | Three status LEDs (bi-color), two of them freely programmable |
