Power supply | 24 VDC (-15/+20 %) |
Max. power | < 3 Watt |
Current consumption | 100 mA |
Cycle time between modules | 1.2 ms |
Size (W x H x D) | ca. 22 x 101 x 115 mm |
Weight | ca. 90 g |
Protection class | IP20 |
Operating temperature | 0 °C to 60 °C |
Storage temperature | -25 °C to 70 °C |
Humidity (40 °C) | up to 93 % (non-condensing) |
Casing material | Polycarbonate |
Galvanic isolation | yes |
Mounting | DIN rail (EN50022) |
